General
Colour of appliance: BlackWidth: 80 cm
Dimensions of the heating elements: 2 x (40,0 x 24,0 cm)
Power of the heating elements: 4 x 2.2 (3.7) kW
Frame type: Design frame
Number of radiant plates: 0
Number of induction plates: 4
heating with booster: All
Controls: illuminated, dual lightSlider, front
Ventilation type: Convertible
Maximum output air extraction: 500 m³/h
Boost position air extraction: 622 m³/h
Maximum output recirculating air: 499 m³/h
Boost position output recirculating: 595.0 m³/h
Sound power at max. speed (2010/30/EC): 69 dB
Sound power boost (2010/30/EC): 74 dB
Noise level: 69 dB(A) re 1pW
Energy consumption of hob: 185.0 Wh/kg
Included accessories: 1 x Slider for unducted recirculation, 1 x Clean Air Plus odor filter
Size and weight
Dimensions: 223x812x520 mmMinimum height for installation: 490 mm
Maximum height for installation: 490 mm
Minimum width for installation: 750 mm
Maximum width for installation: 750 mm
Depth for installation: 223 mm
Appliance height above the worktop: 6.0 mm
Technical specifications
Connection Rating: 7400 WNominal power: 220-240/380-415 V
Length electrical supply cord: 110.0 cm
Plug type: no plug (electrical connection by electrician)
Comfort hob
Type of control: Dual light slider bluehotplate control settings: 17 power levels
Cooking zone flexibility: 2 flex induction cooking zones
powerBoost: Yes
activeLight Plus: No
fryingSensor Plus: Yes
Infrared cooking sensor: No
cookingSensor Plus ready (sensor available as additional purchase): Yes
Powermove: Yes
Power Transfer: Yes
Quick Start: Yes
Keep warm function: Yes
Electronic timer: Yes
Comfort hood
iQdrive: YesBoost position: Yes
Delay Shut off modes: 30R_12E min
Connectivity
Home Connect: YesHome Connect Features: iService Remote
Power consumption standby/display off: 0.5 W
Power consumption standby/network: Please check the user manual for how to switch off the WiFi module.: 2.0 W
Time auto-standby/displ. off: 20.0 min
Time auto-standby/network: 20.0 min
