Description
Design
- Stainless steel surface
- Cast iron pan supports
Usage convenience
- Design co-ordinated control dials: easily access dials in front with strong grip for effortless turning.
- Ignition via control dials: just push and turn the dials to ignite the flame.
Burners and power
- 5 gas burners:
- Left front: economy burner up to 1 kW (depending on gas type)
- Left rear: Standard burner up to 1.75 KW (depending on gas type)
- Center front: wok burner up to 3.3 KW (depending on gas type)
- Right rear: high-speed burner up to 3 KW (depending on gas type)
- Right front: standard burner up to 1.75 KW (depending on gas type)
Safety
- Flame failure safety device: prevents unwanted gas flow when flame goes out.
Installation (gas types & measurements)
- Usable for: NG H/E 20mbar, E+ 20/25mbar
Natural gas H 25 mbar (HU)
Liquid gas G30,31 28-30/37mbar
Liquid gas G30 37 mbar (PL)
Natural gas L 25 mbar (NL)
Liquid gas 50 mbar - Pre-set for natural gas
- Nozzle set for LPG jets included. Connection to 28-30/37 mbar bottled gas. Nozzles for all other gas types can be ordered via the customer service. For nozzle change, please contact the customer service.
- Dimensions of the product (HxWxD mm): 53 x 750 x 520
- Required niche size for installation (HxWxD mm) : 45 x 560 x (480 - 492)
- Min. worktop thickness: 30 mm
- Power cord: 1.5 m
- Connected load: 10.8 KW
General
| Cooktop type | Gas cooktop |
|---|---|
| Self-sufficient cooker control | Self-sufficient gas hobs |
| Width | 75 cm |
| Total number of positions that can be used at the same time | 5 |
| Power of the heating elements | 1 x 1.0 KW, 1 x 3.0 KW, 1 x 3.3 KW, 2 x 1.75 KW |
| Basic surface material | Stainless steel |
| Main colour of product | Stainless steel |
| Energy efficiency of hob | 56.5 % |
Size and weight
| Dimensions | 45 x 750 x 520 mm |
|---|---|
| Minimum height for installation | 480 mm |
| Maximum height for installation | 492 mm |
| Minimum width for installation | 560 mm |
| Maximum width for installation | 562 mm |
| Depth for installation | 45 mm |
| Connection rating | 1 W |
|---|---|
| Gas connection rating | 10,800 W |
| Fuse protection | 3 A |
| Voltage | 220-240 V |
| Length of electrical supply cord | 150 cm |
| Plug type | no plug |
| Gas connection | rear, right |
| Gas type | Nat gas H/E/(L) 20 (25) mbar |
| Alternative gas type | Liquid gas G30,31 28-30/37mbar |
| PowerBoost | No |
|---|---|
| Zone light | No |
| fryingSensor Plus | No |
| Infrared cooking sensor | No |
| PerfectCook sensor ready (sensor sold seperately) | No |
| Powermove | No |
| Setting transfer function | No |
| Quick start | No |
| Keep warm function | No |
| Timer | No |
| FlameSelect | No |
| Wok burner | Yes |
| Type of pan support | Elongated cast iron pan support |
| dishwasher safe pan support | No |
| Ignition system | Yes |
Connectivity
| Smart Appliance | No |
|---|---|
| Cooktop-based hood control | No |
Safety
| Residual heat indicator | without |
|---|---|
| Type of safety device for gas | Electromagnetic for each burner |
