Description
Additional information
Design
- LED-Display Control (Red)
- Rotary dial, Retractable control dials, round
- Straight bar handle
Features
- Control panel lock
- Electronic clock timer
- Interior halogen light
- Integral cooling fan
- 5 shelf positions
- Heating-up indicator
Automatic start
Cleaning
- EcoClean Direct : back panel
Programmes/functions
- Oven with 7 PC heating methods: 3D Hotair, conventional top and bottom heat, Hotair grilling, full width variable grill, pizza function, bottom heat, Hotair gentle
- Fast pre-heating function
Accessories
- 1 x universal pan, 2 x combination grid, 2 x Universal pan, slim size
Performance/technical information
- Energy efficiency rating (acc. EU Nr. 65/2014): A
Energy consumption per cycle in conventional mode: 0.97 kWh
Energy consumption per cycle in fan-forced convection mode: 0.81 kWh
Number of cavities: Main cavity
Heat source: electrical
Cavity volume: 71 litre capacity - Temperature range 50 °C - 275 °C
- Total connected load electric: 2.99 KW
- Nominal voltage: 220 - 240 V
- 120 cm Cable length
- Appliance dimension (hxwxd): 595 mm x 594 mm x 548 mm
- Niche dimension (hxwxd): 585 mm - 595 mm x 560 mm - 568 mm x 550 mm
- Please refer to the dimensions provided in the installation manual
General
| Where can the appliance be installed | Base cabinet, high cupboard installation |
|---|---|
| Are some hobs controls integrated | No |
| Main colour of product | Stainless steel |
| User interface | Red LED display with knob control |
| No. heating modes | 7 |
| Cooking method | Bottom heat, Conventional heat, Full width grill, Hot Air, Hotair gentle, Hot air grilling, Pizza setting |
| Range of temperature (°C) | 50-275 °C |
| Added Steam | No |
| Integrated Cleaning system | Catalytic partial, Hydrolytic |
| Ease of access | Accessory |
| Door hinge | Bottom |
| Usable volume (of cavity) - NEW (2010/30/EC) | 71 l |
| Energy efficiency rating | A |
| Safety device | childproof lock |
| Included accessories | 2 x combination grid, 1 x universal pan, 2 x Universal pan, slim size |
Size and weight
| Dimensions | 595 x 594 x 548 mm |
|---|---|
| Minimum height for installation | 585 mm |
| Maximum height for installation | 595 mm |
| Minimum width for installation | 560 mm |
| Maximum width for installation | 568 mm |
| Depth for installation | 550 mm |
| Net weight | 33.345 kg |
| Plug type | no plug |
|---|---|
| Length of electrical supply cord | 120 cm |
| Voltage | 220-240 V |
| Connection rating | 2,990 W |
| Fuse protection | 13 A |
Comfort
| cookm coolstart | No |
|---|---|
| Fast preheat | Yes |
| Pizza setting | Yes |
| 3D Hotair | Yes |
Connectivity
| Smart Appliance | No |
|---|
