Miele - DA 3366 Stainless Steel - Cooker Hoods

Save $1,540.00
MieleSKU: DA 3366

Note:
This is a genuine parallel import item
Price:
Sale price$7,425.00 Regular price$8,965.00

Description

Product data sheet

Slimline cooker hood Yes

Operating modes

Type of air guide Convertible
Recirculation conversion kit (order separately) DUU 151
Active charcoal filter (order separately) DKF13-1

Design

Colour Stainless steel

User convenience

Mechanical controls Yes
Slide switch Yes
Power levels (number without Booster level) 3
Easy-to-clean canopy interior – CleanCover Yes

Efficiency and sustainability

Energy efficiency class C
Energy efficiency class (A+++ to D) C
Annual energy consumption in kWh/year 61.40
Fluid dynamic efficiency class D
Lighting efficiency class A
Grease filtering efficiency class B

Filter system

Number of dishwasher-safe stainless steel grease filters (10-ply) 1

Lighting

LED Yes
Number x W 2 x 3 W
Light intensity in Lx 320 lx
Colour temperature in K 3000 Kelvin

Blower

Dual-action blower Yes
AC motor Yes

Extraction

Air throughput in Level 1 (m³/h) according to EN 61591 150
Air throughput in Level 2 (m³/h) according to EN 61591 240
Air throughput in Level 3 (m³/h) according to EN 61591 320
Air throughput in Booster level (m³/h) according to EN 61591 430
Sound power in Level 1 (dB(A) re 1 pW) according to EN 60704-3 44.00
Sound power in Level 2 (dB(A) re 1 pW) according to EN 60704-3 47.00
Sound power in Level 3 (dB(A) re 1 pW) according to EN 60704-3 51.00
Sound power in Booster level (dB(A) re 1 pW) acc. to EN 60704-3 58.00
Sound pressure in Level 1 (dB(A) re 20 µPa) according to EN 60704-2-13 32.00
Sound pressure in Level 2 (dB(A) re 20 µPa) according to EN 60704-2-13 35.00
Sound pressure in Level 3 (dB(A) re 20 µPa) according to EN 60704-2-13 38.00
Sound pressure in Booster level (dB(A) re 20 µPa) acc. to EN 60704-2-13 45.00

Recirculation

Air throughput in Level 1 (m³/h) according to EN 61591 80
Air throughput in Level 2 (m³/h) according to EN 61591 150
Air throughput in Level 3 (m³/h) according to EN 61591 200
Air throughput in Booster level (m³/h) according to EN 61591 300
Sound power in Level 1 (dB(A) re 1 pW) according to EN 60704-3 52.00
Sound power in Level 2 (dB(A) re 1 pW) according to EN 60704-3 58.00
Sound power in Level 3 (dB(A) re 1 pW) according to EN 60704-3 61.00
Sound power in Booster level (dB(A) re 1 pW) acc. to EN 60704-3 67.00
Sound pressure in Level 1 (dB(A) re 20 µPa) according to EN 60704-2-13 40.00
Sound pressure in Level 2 (dB(A) re 20 µPa) according to EN 60704-2-13 45.00
Sound pressure in Level 3 (dB(A) re 20 µPa) according to EN 60704-2-13 49.00
Sound pressure in Booster level (dB(A) re 20 µPa) acc. to EN 60704-2-13 55.00

Technical data

Canopy width in in. (mm) 595
Canopy height in in. (mm) 34
Depth of hood canopy in in. (mm) 275
Minimum height above electric hobs in mm 450
Minimum safety distance above gas hobs (max. 12.6 kW total power, burner ≤ 4.5 kW) in mm 650
Net weight in kg 12.00
Length of supply lead in m 1.50
Standard plug fitted Yes
Total rated load in kW 0.12
Voltage in V 230
Fuse rating in A 10
Frequency in Hz 50
Number of phases 1

Installation notes

Extraction ducting connection at top Yes
Diameter of extraction ducting connection in mm 150

Optional accessories

Active charcoal filter No
