Product data sheet
| Heating type | Induction |
Construction type
| Independent of cooker | Yes |
Design
| Elegant glass ceramic surface | Yes |
| Ceramic surface colour | Black |
| Stainless-steel frame | Yes |
| Surface-mounted installation | Yes |
Cooking zone details
| Number of cooking zones | 5 |
| Number of cooking areas | 1 |
| Maximum number of pans | 5 |
PowerFlex cooking zones
| No. | 2 |
| Type | PowerFlex-Kochzone |
| Size in mm | 150x230 |
| Max. rating in W | 2.10 |
| Max. Booster power rating in W | 3.00 |
| Max. TwinBooster power rating in W | 3650 |
1st cooking zone/cooking area
| Position | front left |
| Type | Dual-circuit ring |
| Size in mm | 100-160 mm |
| Max. rating in W | 1400 |
| Max. Booster power rating in W | 1700 |
| Max. TwinBooster power rating in W | 2200 |
2nd cooking zone/cooking area
| Position | rear left |
| Type | TempControl cooking zone |
| Size in mm | 160-230 mm |
| Max. rating in W | 2300 |
| Max. Booster power rating in W | 3000 |
| Max. TwinBooster power rating in W | 3650 |
3rd cooking zone/cooking area
| Position | rear centre |
| Type | Dual-circuit ring |
| Size in mm | 180-280 |
| Max. rating in W | 2600 |
| Max. Booster power rating in W | 3000 |
| Max. TwinBooster power rating in W | 3650 |
4th cooking zone/cooking area
| Position | right |
| Type | PowerFlex bridge |
| Max. rating in W | 3400 |
| Max. Booster power rating in W | 4800 |
| Max. TwinBooster power rating in W | 7300 |
User convenience
| Networking with Miele@home | Yes |
| Automatic function Con@ctivity 3.0 | Yes |
| Operation via sensor controls | Smart Select |
| TempControl | Yes |
| Display colour | Yellow |
| Permanent pan recognition | Yes |
| Pan and pan size recognition | Yes |
| Stop & Go function | Yes |
| Recall function | Yes |
| Minute minder | Yes |
| Safety switch-off | Yes |
| Auto heat-up | Yes |
| Keeping warm | Yes |
| Keeping warm plus | Yes |
| Individual setting options (e.g. buzzers) | Yes |
| Digital power level display | Yes |
Efficiency and sustainability
| Power rating in off mode in W | 0.50 |
| Power rating in standby mode in W | 1.00 |
| Power rating in networked standby in W | 2.00 |
| Time until automatic switch to off mode in min | 20 |
| Time until automatic switch to standby in min | 20 |
| Time until automatic switch to networked standby in min | 20 |
Cleaning convenience
| Easy to clean ceramic glass | Yes |
| Wipe protection | Yes |
Safety
| Safety switch-off | Yes |
| Lock function | Yes |
| System lock | Yes |
| Integrated cooling fan | Yes |
| Overheating protection | Yes |
| Residual heat indicator | Yes |
| Fault monitoring | Yes |
Technical data
| Dimensions in mm (width) | 942 |
| Dimensions in mm (height) | 52 |
| Casing height incl. connection box in mm | 45 |
| Dimensions in mm (depth) | 526 |
| Cutout dimensions in mm (width) with surface-mounted installation | 916 |
| Cutout dimensions in mm (depth) with surface-mounted installation | 500 |
| Weight in kg | 16 |
| Total rated load in kW | 11.00 |
| Voltage in V | 230 |
| Frequency in Hz | 50-60 |
| Length of supply lead in m | 1.40 |
Optional accessories
| Pans | Yes |
