Product data sheet
| Built-under hood | Yes |
Operating modes
| Type of air guide | Convertible |
| Active charcoal filter (order separately) | DKF18-1 |
Design
| Colour | Stainless steel |
User convenience
| Mechanical controls | Yes |
| Slide switch | Yes |
| Power levels (number without Booster level) | 3 |
| Easy-to-clean canopy interior – CleanCover | Yes |
Efficiency and sustainability
| Energy efficiency class (A+++ to D) | C |
| Annual energy consumption in kWh/year | 91.60 |
| Fluid dynamic efficiency class | D |
| Lighting efficiency class | A |
| Grease filtering efficiency class | A |
Filter system
| Number of dishwasher-safe stainless steel grease filters (10-ply) | 2 |
Lighting
| LED | Yes |
| Number x W | 2 x 3 W |
| Light intensity in Lx | 330 lx |
| Colour temperature in K | 3000 Kelvin |
Blower
| Single-action blower | Yes |
| AC motor | Yes |
Extraction
| Air throughput in Level 1 (m³/h) according to EN 61591 | 275 |
| Air throughput in Level 2 (m³/h) according to EN 61591 | 315 |
| Air throughput in Level 3 (m³/h) according to EN 61591 | 355 |
| Air throughput in Booster level (m³/h) according to EN 61591 | 545 |
| Sound power in Level 1 (dB(A) re 1 pW) according to EN 60704-3 | 57.00 |
| Sound power in Level 2 (dB(A) re 1 pW) according to EN 60704-3 | 60.00 |
| Sound power in Level 3 (dB(A) re 1 pW) according to EN 60704-3 | 64.00 |
| Sound power in Booster level (dB(A) re 1 pW) acc. to EN 60704-3 | 74.00 |
| Sound pressure in Level 1 (dB(A) re 20 µPa) according to EN 60704-2-13 | 43.00 |
| Sound pressure in Level 2 (dB(A) re 20 µPa) according to EN 60704-2-13 | 47.00 |
| Sound pressure in Level 3 (dB(A) re 20 µPa) according to EN 60704-2-13 | 50.00 |
| Sound pressure in Booster level (dB(A) re 20 µPa) acc. to EN 60704-2-13 | 60.00 |
Recirculation
| Air throughput in Level 1 (m³/h) according to EN 61591 | 165 |
| Air throughput in Level 2 (m³/h) according to EN 61591 | 180 |
| Air throughput in Level 3 (m³/h) according to EN 61591 | 195 |
| Air throughput in Booster level (m³/h) according to EN 61591 | 220 |
| Sound power in Level 1 (dB(A) re 1 pW) according to EN 60704-3 | 71.00 |
| Sound power in Level 2 (dB(A) re 1 pW) according to EN 60704-3 | 72.00 |
| Sound power in Level 3 (dB(A) re 1 pW) according to EN 60704-3 | 73.00 |
| Sound power in Booster level (dB(A) re 1 pW) acc. to EN 60704-3 | 75.00 |
| Sound pressure in Level 1 (dB(A) re 20 µPa) according to EN 60704-2-13 | 57.00 |
| Sound pressure in Level 2 (dB(A) re 20 µPa) according to EN 60704-2-13 | 58.00 |
| Sound pressure in Level 3 (dB(A) re 20 µPa) according to EN 60704-2-13 | 59.00 |
| Sound pressure in Booster level (dB(A) re 20 µPa) acc. to EN 60704-2-13 | 62.00 |
Technical data
| Canopy width in in. (mm) | 598 |
| Canopy height in in. (mm) | 125 |
| Depth of hood canopy in in. (mm) | 500 |
| Minimum height above electric hobs in mm | 450 |
| Minimum safety distance above gas hobs (max. 12.6 kW total power, burner ≤ 4.5 kW) in mm | 650 |
| Net weight in kg | 11.20 |
| Length of supply lead in m | 1.50 |
| Standard plug fitted | Yes |
| Total rated load in kW | 0.24 |
| Voltage in V | 230 |
| Fuse rating in A | 10 |
| Frequency in Hz | 50 |
| Number of phases | 1 |
Installation notes
| Extraction ducting connection at top | Yes |
| Diameter of extraction ducting connection in mm | 150 |
| Fitting template | Yes |
Optional accessories
| Active charcoal filter | No |
